Street pavement
markers delineators
Street level pavement
markers studs
Street level pavement
markers delineators
Street level pavement markers
Street level pavement markers
We Guarantee YOU will LOVE our Great Customer Service and Affordable Prices
Road Safety
UNLIKE ANY ON the PLANET
PUT YOUR SAFETY ON IT
Great Manufacturer Prices
Installation of our products is easier than you think and our live customer support is free, and free is good!
STREET LEVEL
MARKERS TCB-1
DIMENSIONS
Length 4" Width 4" Height 0.75"
TCB-1 pavement markers are
designed with a high power
reflective lens set into a non
aggressive rounded shoulder
incline for smooth roll over.
The TCB-1 is shatter proof, with
a special hard coat protecting
the prismatic lens from abrasion.
Angled prisms provide optimum
night visibility.
TCB-1 Pavement
studs are available in
single and double
sided reflective lens.
studs are available in
single and double
sided reflective lens.
Colored housing with
matching lens for
day
time visibility.
Adhesion: Stick-fast
instant pre-cut
Butyl
pads, Hot melt or
adhesive can be
used.
Colors: white, amber, blue, green
and red.
Combinations: red-amber, red-
white.
Colors: white, amber, blue, green
and red.
Combinations: red-amber, red-
white.
|
Color
|
Color
|
Item #
|
|
|
|
|
Single
|
Double
|
|
white
|
white
|
0310-W
|
0312-WW
|
|
amber
|
amber
|
0310-A
|
0312-AA
|
|
red
|
red
|
0310-R
|
0312-RR
|
|
blue
|
blue
|
0310-B
|
0312-BB
|
|
green
|
green
|
0310-G
|
0312-GG
|
|
Combinations
|
|
|
|
|
Color
|
Color
|
|
Double
|
|
red
|
amber
|
|
0312-RA
|
|
red
|
white
|
|
0312-
RW
|
|
Cost
|
|
Single
sided
$
|
Double
sided
$
|
|
Adhesive Quick
stick pads
|
|
Cost
|
|
Cold stick butyl
pads
Hotmelt Stick fast
pads
|
0950-CSF
0950-HSF
|
|
|
|
|
$
|
STREET LEVEL
MARKERS TCB-5
STREET LEVEL
MARKERS TCB-10
DIMENSIONS
Length 3.94" Width 3.94" Height 0.7"
Highly reflective "Cat's Eye" road studs reflect light similar to "LED" type lighting.
The TCB-5 provides durability and longevity when installed in areas of significant traffic flow or
in dry, sandy climates.
Shatter proof, the TCB-5 outlasts most markers by its unique one piece design. Manufactured with 45 glass elements on each face for optimum visibility.
TCB-5 has recessed "grabbers" for easy installation.
Colors: white, amber, blue green, red and fluorescent yellow.
Length 3.94" Width 3.94" Height 0.7"
Highly reflective "Cat's Eye" road studs reflect light similar to "LED" type lighting.
The TCB-5 provides durability and longevity when installed in areas of significant traffic flow or
in dry, sandy climates.
Shatter proof, the TCB-5 outlasts most markers by its unique one piece design. Manufactured with 45 glass elements on each face for optimum visibility.
TCB-5 has recessed "grabbers" for easy installation.
Colors: white, amber, blue green, red and fluorescent yellow.
TCB-5 pavement
studs are available
in single or double
sided lens units.
|
Color
|
Color
|
Item #
|
|
|
|
|
Single
|
Double
|
|
white
|
white
|
3551-W
|
3552-WW
|
|
amber
|
amber
|
3551-A
|
3552-AA
|
|
red
|
red
|
3551-R
|
3552-RR
|
|
blue
|
blue
|
3551-B
|
3552-BB
|
|
green
|
green
|
3551-G
|
3552-GG
|
|
Combinations
|
|
|
|
Fluorescent yellow
|
3552-FLY +
Color
|
|
|
Any combination
|
3552-FLY +
Color
|
|
|
all
|
|
|
|
Cost
|
Single sided $
|
Double sided $
|
|
Adhesive Quick
stick pads
|
|
Cost
|
|
Cold stick butyl
pads
Hotmelt Stick fast
pads
|
0950-CSF
0950-HSF
|
|
|
|
|
$
|
DIMENSIONS
Length 8.6" Width 3.94" Height 1.57"
City Studs are designed for both
permanent and temporary applications such as curbs, tunnels, bridges and rotaries. Divide bus and taxi lanes from free-flow traffic.
Highly visible oversize markers
define roadsides by its 179 glass element count. Single or double sided, with or without metal supports.
Length 8.6" Width 3.94" Height 1.57"
City Studs are designed for both
permanent and temporary applications such as curbs, tunnels, bridges and rotaries. Divide bus and taxi lanes from free-flow traffic.
Highly visible oversize markers
define roadsides by its 179 glass element count. Single or double sided, with or without metal supports.
Bonds perfectly to asphalt and
concrete surfaces.
concrete surfaces.
TCB-10 City Studs are available
with metal supports for additional
strength when installed in
sensitive areas.
179 Glass elements per side
45 Glass elements per side
|
Color
|
Color
|
Item #
|
|
|
|
|
Single
|
Double
|
|
white
|
white
|
5001-W
|
5002-WW
|
|
amber
|
amber
|
5001-A
|
5002-AA
|
|
With
Stem
|
|
|
|
|
white
|
white
|
5001-W
|
5002-WW
|
|
amber
|
amber
|
5001-A
|
5002-AA
|
|
Cost
|
No
stem
|
Single sided
$
|
Double
sided $
|
|
Cost
|
No
stem
|
Single sided
$
|
Double
sided $
|
Adhesive pads are available in cold
"Peel and Stick" applications for
areas were heat and flame are
restricted or cannot be used.
All other typical installations
Hotmelt stick pads may be used.
STREET LEVEL MARKERS TCB-15
DIMENSIONS
Length 8.6" Width 5.9" Height
11.2"
Lane Dividers
are temporary delineators that provide excellent day/night time warning guidance to road users.Equipped with a flexible rubber shaft adding a reliable means to stop dangerous lane changing. Absolutely
traversable, even in heavy traffic areas. Single or double sided. With or without rubber shaft. Shaft equipped with
stud reflector for enhanced visibility.
TCB- 15 Delineators are available with
metal
supports for addi t ional anchoring strength
in sensitive areas.
Divider stud without rubber shaft.
128 Glass elements per side.
|
Marker
Color
|
Shaft
Color
|
Item #
|
|
|
|
|
Single
|
Double
|
|
white
|
red
|
5058-WR
|
5058-WWR
|
|
yellow
|
red
|
5020-YR
|
5020-YYR
|
|
yellow
|
yellow
|
5017-YY
|
5018-YYY
|
|
Yellow
stud
|
|
5005-Y
|
5006-YY
|
|
White
stud
|
|
5005-W
|
5006-WW
|
|
With Stem
|
|
|
|
Add "S" to item
numbers
|
|
|
|
Adhesive
|
Item #
|
|
|
Cold stick Butyl
pads
Hot stick Butyl
pads
|
0952-CSF
0952-HSF
|
|
|
Cost
|
No
stem
|
Single sided
$
|
Double
sided $
|
|
Cost
|
With
stem
|
Single sided
$
|
Double
sided $
|
INSTALLATION SOLUTIONS
If adhesive dispensing machinery is not available, use quick stick bituminous pads for pavement and
concrete surfaces.
1) Peel off protective liner
and adhere adhesive pad to
surface.
2) Using blow torch, burn
off thin plastic layer.
3) Place pavement marker
on melted Quick Stick Pad
and press firmly. Open to
traffic.
PAVEMENT MARKERS
PAVEMENT STUDS STREET LEVEL MARKERS
PAVEMENT MARKERS
Adapting to todays demands for retroreflectivity.Proven studies show that reflective road studs are among the most effective safety products in all adverse weather conditions.
Reflector Road Studs
offer optimum lane identification in all weather conditions. They are visible and can be heard and felt, due to the rumble when a vehicle crosses them. Installed on thousands of miles of roadways throughout the world. Tire action facilitates the self-cleaning feature, keeping the reflective surface clean and brilliant.Road Studs
offer a low cost alternative for enhancing roadways and turns. Retroreflection increases visibility which, in turn, increases safety.
