Diamond Core Drilling Rigs
Diamond Core Drilling Rigs
Drilling Core Machines
Drilling Core Machines
TOOLS
PRECISION Drilling core machines
Drilling Core Machines and Diamond Core Drilling Rigs
for Reflective Glass Curb Pavement Markers, Road Glass Studs
Drill 1" up to 10" holes with a Bantam diamond core drilling rig.
High powered precision tilting DRILLING PRESS is an easy to use
High powered precision tilting DRILLING PRESS is an easy to use
diamond core drilling machine
capable ofcoring marble, granite, concrete, rebar and asphalt
from 1 inch up to 10 inches easily. Designed for quick set up, the Bantam SEL has a telescoping multi positioning strut enabling instant inclines and stability.
Ask about our rental program
CORE DRILLING Machines
DIAMOND Cores
Bantam FAST CORE drill bits offer a new
technology in diamond bit design.
The combination of all these elements allows for
faster coring.
Bantam FAST CORE drill bits offer a new
technology in diamond bit design.
Bantam Fast Core drilling
bits are manufactured with a kerf thickness half that of most common bits allowing less feed pressure. This design cuts less material with enhanced cutting power.The combination of all these elements allows for
faster coring.
Equipped with suction gage
and air flow adjustment
knob for precision drilling
control.
and air flow adjustment
knob for precision drilling
control.
Built-in Neoprene vacuum seal for suction adhesion. Use on concrete, pavement and most surfaces with equal or similar porosity.
Vacuum pump assembly
with suction gage.
with suction gage.
Quickly install sign posts on raised curbing. Easily bore 8" cores for V-Lock type sign supports.
Easy clip-on water line assures constant water flow for prolonged bit life. In addition to its powerful 20 Amp motor and three drilling speeds, the Bantam 1000 SEL has been designed to compliment Reflector glass curb and pavement marker installations with its dual handles, rear wheels, and easy turn hand knobs for instant stability and functionality.
Diamond Core Drilling Machine FEATURES
• Single man wall drilling
• Quick tilt for angle drilling
• Instant inclines and stability
• Built in hole locator
• Easy clip-on water line
• Built in vacuum pad
• Overload protection
• Telescoping multi positioning strut
• Quick tilt for angle drilling
• Instant inclines and stability
• Built in hole locator
• Easy clip-on water line
• Built in vacuum pad
• Overload protection
• Telescoping multi positioning strut
SPECIFICATIONS
Core sizes: 1" to 10" Holes Amps: Amps: 20
Gear box: 3 speed,
RPM Speeds: 400 - 600 - 1200
Maximum Height: 36"
Base: 10 1/2" x 15 1/2"
Weight: 65 lbs
Core sizes: 1" to 10" Holes Amps: Amps: 20
Gear box: 3 speed,
RPM Speeds: 400 - 600 - 1200
Maximum Height: 36"
Base: 10 1/2" x 15 1/2"
Weight: 65 lbs
Specifically designed for Pavement Reflector Markers 2" and 4" glass markers
Prices reflect single units only, please contact us for quantity pricing
Prices reflect single units only, please contact us for quantity pricing
DIAMOND CORE DRILLING RIGS AND EQUIPMENT
For glass curb and pavement markers
Diamond core drilling equipment and machines
designed to installglass curb
and pavement markers
quickly and effortlessly.Holotool TE 76 is our top of the line
drilling core machine
specifically designedto install large volumes of
curb markers
. The DD 160 offers multiuse drilling witha 1 to 9 inch wide core capability. The DD 130 is a lightweight easy to use
drilling core that is easy manageable and cost effective.
Drilling rigs with
recommended diamond drilling cores
offer precision drilling characteristicsdesign to support and secure Reflector glass curb and pavement markers.
TE 76
Requires BU
type bit
type bit
$ 9800.00
Item # USR-MDM-01
Item # USR-MDM-01
Holotool TE 76 Core rig system has been specifically designed to quickly hug curbs for precise hole drilling. Utilizing the same electrical components as the DD 160E, the TE 76 has been equipped with a reinforced transmission and ground support platform.
The TE 76 Core rig system is recommended for continuous installations of both curb and pavement markers.
The TE 76 Core rig system is recommended for continuous installations of both curb and pavement markers.
DD 160 RIG
Requires BU
type bit
type bit
$ 2740.00
Item # USR-DD-160
Item # USR-DD-160
DD 160E is a multi function drill press for drilling precise core holes from 1inch to 9 inches in diameter.
Drill steel-reinforced concrete, natural stone, masonry and asphalt. DD 160 is powered by a 115 V, 2000 watt motor with three functioning speeds: 500, 1000 and 2000 rpm's. Use for both
Drill steel-reinforced concrete, natural stone, masonry and asphalt. DD 160 is powered by a 115 V, 2000 watt motor with three functioning speeds: 500, 1000 and 2000 rpm's. Use for both
curb and pavement marker
installations.
DD 130 RIG
TE 76
CURB MARKER DIAMOND CORE BITS
Wet Diamond Core Bits
are designed to drill reinforced concrete, natural stone, masonry and asphalt. Opti-Curb Markers require ”Holotool” diamond core drill bits built with a countersink cutting head to assure proper curb marker installation and positioning. 360O Markers require a 4 1/4" inch diamond core bit.
2" DIAMOND CORE BIT
4" DIAMOND CORE BITS
4 1/4 inch diamond core drill bit for installing
360 and 180 degree pavement markers.
360 and 180 degree pavement markers.
Requires BI
type bit
type bit
$ 2220.00
Item # USR-DD-130
Item # USR-DD-130
Versatile, mobile and efficient Cores quickly and neatly into reinforced concrete, natural stone, masonry and asphalt Designed for both wet and dry coring without modification. Can be set up and operated easily by one individual. 1800 W motor with plenty of reserve power. 3-speed gearing for optimum coring performance. Fits 15/32" to 6" Diamond cores.
COMPLETE RIG KIT Includes: DD 130, drilling rig, water tank, wheels and 2" & 4" core drilling bit: $3450.00
COMPLETE RIG KIT Includes: DD 130, drilling rig, water tank, wheels and 2" & 4" core drilling bit: $3450.00
Features
• Quick adjustment to curb edges
• Workable foot platform designed
specifically for curb marker
installations
• Quick adjustment to curb edges
• Workable foot platform designed
specifically for curb marker
installations
Benefits
• Service indicator light to prevent
motor damage. 3-speed gearing for optimized core drilling speed.
• Mechanical slip clutch for motor protection.
• DD-BU quick-release chuck
• No tools required for operation.
• Service indicator light to prevent
motor damage. 3-speed gearing for optimized core drilling speed.
• Mechanical slip clutch for motor protection.
• DD-BU quick-release chuck
• No tools required for operation.
